Chris's Dream Machine Bus

Toyota 2014 Coaster

Layout Options

Optimised baseline: raised rear queen, child bunks along driver side, combined wet room midship, and fresh water/batteries in a low undercarriage bay.

Custom Layouts

Layout name

Not saved as custom

Save a preset or edited plan as a custom layout, then rename it for comparison.

Add Fixtures

Selected

Ghosted passenger entry door

Locked

45 x 760 x 1750 mm, approx 0 kg

No image configured

Width X

Length Z

Height Y

Weight

Image URLSource URLSource label

X880 mm

Z-2020 mm

Yaw0 deg

Centre Y875 mm

Base0 mm

Top1750 mm

Position X

Position Z

Position Y

Yaw

deg

Move: select Move, drag the coloured arrows, release the mouse, then press Lock item.

Snap: items within 35 mm of a wall or the floor snap flush. Move past that zone to keep a gap.

Keyboard: arrow keys move 50 mm, Shift + arrows move 250 mm, Enter locks or unlocks.

Rotate: select Rotate or use 90 deg. Locked items stay fixed.

Hide: temporarily remove this item from the scene and clash checks.

Layout Items

Space Metrics

Interior L5310 mm

Interior W1810 mm

Interior H1900 mm

Fixture mass500 kg

Interior numbers are a working estimate. Replace with measured dimensions before fabrication.

Validation

Ghosted passenger entry door requires evidence or licensed/certifier review: reference-only, left-side-entry, access-clearance, certifier-review-if-modified.
Raised queen bed is heavy and currently high; keep heavy loads low and verify axle impacts.
Toilet shower unit is heavy and currently high; keep heavy loads low and verify axle impacts.
Cooktop requires evidence or licensed/certifier review: cooking, lpg-or-induction-review, ventilation.
Dinette requires evidence or licensed/certifier review: seating, possible-child-bed, certifier-review-if-travel-seat.
Battery in undercarriage bay requires evidence or licensed/certifier review: 12v, lithium-review, low-heavy-item.
ADR/compliance status remains evidence-required until reviewed by the relevant certifier and licensed trades.

Hidden Items

Hidden fixtures are removed from the scene and clash checks until shown again.

Legend

Queen bedChild bed / bunkConvertible dinette85L fridgeCooktop moduleShower moduleAll-in-one toilet shower
